| Features |
|
| Aluminium Extrusion Heat Sink |
Yes (Separate) |
| Balance / Bass / Treble / Loudness |
Yes / Yes / Yes / No |
| Channels |
2 |
| Current Feedback Topology |
Yes |
| Customised Components |
Yes |
| Digital In: USB-B / Optical / Coaxial / USB-A |
No / No / No / No |
| HDAM Version |
SA3, SA2 |
| High Grade Audio Components |
Yes |
| Phono EQ: Standard / Marantz Musical / Marantz Musical Premium |
No / No / Yes |
| Power Transformer: Toroidal / El |
SMPS |
| Symmetric PCB Layout |
Yes |
| General |
|
| Auto Power Off |
Yes |
| Carton Maximum Dimensions (W x D x H) |
534 x 522 x 255 mm |
| Carton Weight (inc. product) |
17.6 kg |
| Detachable Power Cable |
Yes |
| Maximum Dimensions (W x D x H) |
443 x 431 x 130 mm |
| Metal Front Panel |
Yes |
| Power Consumption |
130 W |
| Remote Control |
RC002PMND |
| Standby Consumption |
0.2 W |
| System Remote Function |
Yes |
| Weight |
14.8 |
| Inputs Outputs |
|
| Audio Inputs |
6 |
| Audio Outputs |
1 |
| Balanced In / Out |
No / No |
| D-Bus |
Yes |
| Digital In: USB-B / Optical / Coaxial / USB-A |
No / No / No / No |
| Floating Control Bus (3.5mm mono jack x 2) |
No |
| Gold Plated Cinch |
Yes |
| HDMI: Inputs/Outputs |
No |
| Headphone Gain Control (Low / Mid / High) |
No |
| Headphone Out |
Yes |
| Number of Terminals |
2 |
| Phono Input: MM / MC |
Yes / Yes |
| Power Amp Direct IN |
Yes |
| Pre-Out / Main-In |
Yes / No |
| Speaker A/B |
No |
| Speaker Terminals |
Marantz SPKT-100+ |
| Others |
|
| 5mm Aluminium Top Plate |
No |
| BI-AMP and Multichannel Option |
No |
| Double Layer Bottom Plate |
Yes |
| Input Buffer Amp (All Inputs / CD Only) |
No / No |
| Linear Drive Power Supply |
Yes (pre-amplifier stage) |
| Linear Volume Control |
Yes |
| Low Noise LCD Display |
No |
| Low Noise OLED Display |
Yes |
| Marantz Musical Digital Filtering |
No |
| Power Amp Direct |
No |
| Shottky Diodes |
Yes |
| Source Direct |
No |
| System Block Shielding: Copper / Metal / None |
Yes / No / No |
| Damping Factor |
500 |
| Frequency Response |
5Hz - 50kHz |
| Input Sensitivity: Balanced High Level |
No |
| Input Sensitivity: High Level |
220mV / 13kOhm |
| Input Sensitivity: MC |
250 |
| Input Sensitivity: MM |
2.3mV / 39kOhm |
| Input Sensitivity: Power Amp Direct IN |
No |
| Power Output (8 / 4 Ohm RMS) |
100 W / 200 W |
| Signal to Noise Ratio: High Level |
107 dB (2V input/Rated output) |
| Signal to Noise Ratio: MM/MC |
88 / 75 dB |
| Signal to Noise Ratio: Power Amp Direct IN |
No |
| Total Harmonic Distortion |
0.005% |
