The KEF Ci200.3QT sits within KEF's Ci Motorised Series — a specialist range of architectural speakers engineered to disappear completely into the ceiling when not in use. Unlike conventional in-ceiling speakers that remain permanently visible, the motorised mechanism allows the Ci200.3QT to lie flush with the ceiling surface and deploy silently at the touch of a remote or via a trigger voltage, making it a natural partner for motorised projection screens in fully automated home cinema installations. In commercial settings, the same disappearing act suits boardrooms and presentation spaces where visual discretion is paramount.
Driver Technology
The Ci200.3QT is a two-way design built around a 200mm (8”) polypropylene cone bass/mid driver with a coincident-mounted 25mm (1”) aluminium dome tweeter. The tweeter is ferrofluid cooled for improved power handling and thermal stability. This coaxial arrangement — mounting the high-frequency unit at the acoustic centre of the bass cone — delivers consistent dispersion characteristics across the listening area, which is particularly important for ceiling-mounted speakers where listeners are rarely positioned directly on-axis.
ACE Technology & Motorised Deployment
KEF's proprietary ACE (Acoustic Compliance Enhancement) technology extends the low-frequency response from the bass driver, allowing the sealed enclosure to reach deeper than its physical volume would normally permit. Five pre-set tilt positions allow the installer to aim the driver precisely at the primary listening position, compensating for off-axis placement. The motorised mechanism can be configured to deploy automatically when an audio signal is detected, or controlled manually via a low-voltage trigger input.
Installation
The Ci200.3QT requires a rectangular ceiling cut-out of 363 × 260 mm with a mounting depth of 210 mm. The machined aluminium front baffle and steel mounting bracket ensure a rigid, rattle-free installation. Both the bezel and grille can be painted to match the surrounding ceiling finish, maintaining a clean, unobtrusive appearance even when deployed.
