| HDMI Standard | HDMI 2.0 (a/b), HDCP 2.2 |
|---|
| Data Rate | 18Gbps |
|---|
| Max Range (4K UHD) | 100m over single Cat cable |
|---|
| Max Range (1080p) | 150m (long-range mode) |
|---|
| Max Resolution | Ultra HD 4K 60Hz 4:4:4 |
|---|
| HDR Formats | Dolby Vision, HDR10, HLG |
|---|
| Audio Formats | Up to Dolby Atmos and DTS:X |
|---|
| Compression | Tipping Point Compression (TPC) with DSC |
|---|
| Audio Return | RX>TX via Optical or HDMI-ARC to Optical on TX |
|---|
| Ethernet | 2x 10/100 LAN at RX |
|---|
| Power | Bi-directional PoH (powered from RX or TX) |
|---|
| Cable Required | Single Cat cable (twisted pair) |
|---|
| Control | Bi-directional IR and RS232 |
|---|
| In the Box | TX unit, RX unit, IR cabling, mounting kit, multi-territory power adapters |
|---|
