| Power Amplifier |
|
| Number of Powered Channels |
2 |
| Power Output |
75 W (8 ohm, 20 Hz–20 kHz, 0.08% 2ch Drive) 100 W (6 ohm, 1 kHz, 0.7% 2ch Drive) 150 W (6 ohm, 1 kHz, 10% 1ch Drive) |
| Discrete Power Amplifier |
Yes |
| Inputs/Outputs |
|
| Video |
HDMI In / Out - 6/1 |
| Audio |
Analog In / Fixed - 3 in / 0 out Phono (MM) In / Yes Digital In: Optical / Coaxial - 1 / 1 Multi-Room Out: Analog / Digital - 1 / 1 Multichannel Pre-Amp Out: 2.2 Subwoofer Out: 2 |
| Other Features |
Number of Speaker Terminals - 4 Speaker A/B USB type A Audio (Host) AM/FM Tuner |
| HDMI |
|
Total Inputs
|
6 |
| 8k Support Inputs |
3 |
| HDMI Outputs |
1 |
| HDMI Upscaling |
1080p/4K to 8K |
| Max Resolution |
1080p/4K to 8K |
| Audio Return Channel |
ARC |
| Video Dynamic Range |
HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR |
| Other Features |
HDCP 2.3 Support ALLM (Auto Low Latency Mode) Pass-Through for Gaming Variable Refresh Rate / Quick Frame Transport HDMI Pass-through in Standby Mode CEC Auto LipSync |
| Performance Technologies |
|
| Features |
Hyper Dynamic Amplifier Modules (HDAM) Pure Direct Mode Gold-Plated RCA Terminals |
| Music File Support |
|
| Lossy Formats |
MP3 / WMA / AAC |
| Lossless Formats |
FLAC HD 192/24, WAV 192/24, ALAC 192/31 |
| DSD Audio |
2.8MHz / 5.6MHz |
| Gapless Playback |
FLAC, WAV, ALAC, DSD |
| Other Features |
Compressed Audio Enhancer: MDAX2 Network Audio Sharing |
| Streaming Services |
|
| Featured Services |
HEOS® Multi-Room and Streaming AirPlay2 Internet Radio: TuneIn Spotify Connect Pandora SiriusXM Amazon Music HD TIDAL Deezer iHeart Radio Napster Soundcloud Mood Mix Roon |
| Network Connectivity |
|
| Connectivity Features |
Ethernet Ports Wi-Fi Bluetooth Bluetooth Re-Transmit for Bluetooth Headphones (with volume control) |
| Smart Home Integration & Control |
|
| Voice Assistant Compatibility |
Alexa, Google Voice Assistant, Apple HomePod, JoshAi |
| Smart Device App (iOS/Android) |
Marantz AVR App |
| Multi-Room Zones |
1 |
| Zone Audio Source |
2 Ch HDMI/OPT, 2 Ch Coax/Network, USB/Analog |
| Zone Audio Output |
Pre-Out |
| Control Connectivity |
IP Control, Web Control, App Control, HDMI Diagnostics |
| Other Features |
HEOS Multi-Room Integrated HEOS Link Compatibility: IR/IP Zone HDMI Output from HDMI Source IR Flasher In Marantz Remote Bus |
| Maximum Dimensions (W x D x H) |
Antenna, Horizontal: 17.4 x 15.2 x 4.3 in. Antenna, Vertical: 17.4 x 15.2 x 7.0 in. w/o Antenna: 17.4 x 14.7 x 4.3 in. |
| Weight |
18.5lbs |
