Stylus Type
Bonded Spherical
Stylus Tracking Radius
15 µm (0.6 mil)
Equivalent tip mass
0.7 mg
Frequency Response
20 Hz – 20 kHz ± 3 dB
Frequency Range
12 Hz – 20 kHz
Channel Imbalance
1.5 dB max at 1 kHz
Channel Separation
20 dB min at 1 kHz
Sensitivity
3.5 mV ± 3 dB at 5 cm/s lateral
Static Compliance
20 mm/N
Vertical Tracking Angle
24 °
Load Capacitance
100 - 200 pF (150 pF nominal)
Internal Inductance
400 mH
Internal Resistance
470 Ω
Cartridge Mass (inc. fixings)
7.8 g
Playing Weight
1.75 – 2.25 g (2 g nominal)
Recommended Tonearm Effective Mass
10 – 30 g
